Automotive

Automotive Applications

Development of Cross-Domain Architectures

The transition from domain-based to cross-domain architectures requires a fundamental rethink in network analysis. End-to-end latencies become critical, and isolated analysis of individual subsystems is no longer sufficient. With the evolution of standards such as TC-18, the importance of holistic system testing is increasing: individual components may function in isolation, but unexpected effects and timing issues often arise in the overall system.

In-Vehicle Logging

Vehicle testing is a key element in validating modern vehicle architectures. Many timing-related effects in networks only occur under real driving conditions. Analyzing network traffic in the vehicle under real load conditions quickly reveals misbehavior.

Shift-Left Development

Increasing virtualization is fundamentally changing the development process. Network communication must be analyzed and validated even before real hardware is available. Early insights into deterministic behavior make it possible to detect errors at an early stage and significantly reduce development risks.

____

TSN CoreSolution

Precision. Reliability. Trust.

Time-Sensitive Networking (TSN) is redefining in-vehicle communication. With the TSN CoreSolution – the combination of TSN Box and TSN Tools – you gain the ability to analyze, validate, and optimize Automotive Ethernet networks with nanosecond precision.
From lab environments to real vehicles, the TSN CoreSolution provides full transparency into deterministic communication – helping developers detect issues early, reduce integration risks, and accelerate development cycles.

Support for Next-Generation Automotive Architectures

Cross-Domain Architectures
Validation of communication between zones and central compute units to ensure deterministic data transmission across the entire vehicle network.

ADAS & Sensor Fusion
Analysis of time-critical data streams and ensuring low-latency, synchronized communication between sensors, ECUs, and compute platforms.

In-Vehicle Network Debugging
Detailed insights into network traffic directly in the vehicle or on test benches – including latency, jitter, and packet loss.

Integration & System Testing
Early detection of timing issues, misconfigurations, and prioritization conflicts in lab environments before they affect vehicle testing.

Mixed-Criticality Networks
Ensuring reliable interaction between TSN, best-effort Ethernet, and legacy protocols in complex automotive systems.

Benefits

Accelerate your time-to-market by reducing debugging effort, avoiding late-stage issues, and ensuring predictable network behavior from development start to SOP.

TSN Systems Automotive Products

Development	TSN CoreSolution 3 100 Mbit & 1 Gbit CAN, LIN, 10Base-T1S Precise GPIO TSN Tools Support More information TSN CoreSolution 3 A²B 100 Mbit & 1 Gbit CAN, LIN, 10Base-T1S A²B Precise GPIO TSN Tools Support More information TSN CoreSolution 4 High-Performance Passive ‑ Capture up to 10 Gbit/s Super-fast internal SSD TSN Tools Support More information	Analysis & Logging TSN Tools More information TSN, best-effort Ethernet and Legacy

Logging	TSN BasicSolution TSNAP Logging of 2 x 100Mbit / 1 Gbit Internal SSD Filter- & Trigger Functions Remote Control TSN Tools Support More info TSNAP 1 More info TSNAP 2 TSN BasicSolution OctoCAN Development & Analysis of CAN and LIN 8x CAN, 8x LIN TSN Tools Support More information

Media Converter	TSN BasicSolution Media Converter Easy pairing of BASE-T & BASE-T1 1G & up to 10G speeds TSN Tools Support More info SMC 1G More info SMC 10G

Infrastructure	TSN BasicSolution Switch 1G & 10G Suitable for mixed-criticality networks Support for relevant 802.1DG mechanisms Predictable network behavior for integration and V&V TSN Tools Support More info Switch 1G More info Switch 10G

Synchronization	TSN BasicSolution Timepiece IEEE 802.1AS 2011/2020 Grand Master GNSS support TSN Tools Support More information
